ILSCO CLWD-6-14-58 Surecrimp Copper Compression Lug, Conductor Size 6, 2 Holes, 1/4in Bolt Size, 5/8in Hole Spacing

Product Description

The ILSCO CLWD-6-14-58 is a copper compression lug designed for conductor size six. It features two holes with a quarter-inch bolt size and five-eighths inch hole spacing. The long barrel design makes it easy to use and is ideal for high conductivity applications.

• Manufactured from seamless copper tubing.
• UL Listed and CSA Certified.
• Color coded for die identification.

Product Highlights

This copper compression lug offers excellent crimping characteristics and reduces contact resistance through its electro-tin plating. It is suitable for various applications, including those requiring efficient electrical connections.

Product Information

Standard Information

• Catalog Number: CLWD-6-14-58
• Manufacturer: ECM Industries

Technical Specifications

• Barrel Length: 1.125 inches
• Conductor Size: 6 AWG
• Stud Size: 1/4 inch
• Pad Hole Spacing: 5/8 inch
• Material: Seamless electro-tin plated copper
• Approval: UL 453G, UL 467, UL 486A/B, CSA
