Ilsco CLNF-600-12-134 Compression Lug, Copper, 2-Hole

Product Description

The ILSCO CLNF-600-12-134 is a copper compression lug with 2 holes. This lug is electro-tin plated for corrosion resistance and suitable for use in circuits rated 35KV or less, when using proper high voltage spacing and insulation techniques. It features a chamfered entry for ease of conductor insertion and color coded ink marking signifies key details including correct die.

• Electro-tin plated for corrosion resistance
• Suitable for use in circuits rated 35KV or less, proper high voltage spacing and insulation techniques must be used
• UL Listed and CSA Certified with ILSCO and major competitor's tools for application versatility

Product Highlights

The ILSCO CLNF-600-12-134 compression lug is manufactured from high strength copper, provides low contact resistance, and is rated to 90 degrees C.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: CLNF-600-12-134
• Country of Origin: United States

Technical Specifications

• Material: Copper
• Mounting: 2-Hole
• Allowable Gauge Range: 600
• Stud Size: 1/2 in
• Termination Type: Compression
• Country of Origin: United States
• Product Series: CLNF
• Family Series: Ilsco Terminals, CLNF Series
• Description: CU CMP 600 9/16 T
• Wire Size Range: 250-600 kcmil
• Number of Conductors: 1
• Applications: Copper Compression Lug
• Bolt Size: 1/2 IN
• Split Crucible: N
• Temperature Rating: 90 degrees C
• Type: CLNF:LONG FLARED BARREL
• Voltage: 35,000 Volt
• Brand: Ilsco
• Sub Brand: Surecrimp
