Product Description
ILSCO CLND-8-10-58 is a compression cable lug designed for effective and reliable electrical connections. This product features a long barrel and is made from high-strength seamless copper tubing. It is suitable for use with conductors sized eight AWG and features ten bolt holes spaced five eighths inches apart.
- Manufactured from high-strength seamless copper tubing.
- UL Listed and CSA Certified.
- Designed for easy conductor insertion with chamfered entry.
Product Highlights
This compression cable lug offers maximum conductivity and excellent crimping characteristics. Its long barrel design allows for versatility in applications, including high-voltage environments.
Product Information
Standard Information
-
Manufacturer: ILSCO
-
Product UPC: 783669627862
Technical Specifications
-
Barrel Length: 0.812 Inch
-
Approval: UL 453G, UL 467, UL 486A/B, CSA
-
Material: Seamless Electro-Tin Plated Copper
-
Conductor Size: 8 AWG
-
Stud Size: #10
-
Number of Pad Holes: 2
-
Pad Hole Spacing: 5/8 Inch
-
Pad Size: 1.25 Inch L x 0.374 Inch W x 0.093 Inch Thk
-
Die Index: I-21
