Product Description
The Ilsco CLND-750-12-134 is a copper compression lug designed for use with conductors of size 750 kcmil. This product features a long barrel and two bolt holes for secure connection. The barrel length measures 2.875 inches.
- UL Listed and CSA Certified
- Long barrel with chamfered entry for easy installation
- Seamless electro-tin plated copper for maximum conductivity
Product Highlights
Ideal for connecting large conductors in various electrical projects, this compression lug provides reliable performance.
Product Information
Standard Information
-
Brand: Ilsco
-
MPN: CLND-750-12-134
Technical Specifications
-
Approval: UL 453G, UL 467, UL 486A/B, CSA
-
Barrel Length: 2.875 inches
-
Barrel Type: Long
-
Conductor Material: Copper
-
Conductor Size: 750 KCMIL
-
Number of Pad Holes: 2
-
Stud Size: 1/2 inch
-
Pad Hole Spacing: 1-3/4 inches
