Ilsco CLND-350-38-1 2-Hole Lug

Product Description

The ILSCO CLND-350-38-1 is a Surecrimp copper compression lug with a conductor size of 350. It features 2 holes and a 3/8in bolt size. This lug is manufactured from high strength seamless copper tubing and is electro-tin plated. Suitable for use in circuits rated 35KV or less.

• Manufactured from high strength seamless copper tubing
• Electro-Tin plated
• Chamfered entry

Product Highlights

This copper compression lug is UL Listed and CSA Certified with ILSCO and major competitor’s compression tools and is rated to 90 degrees C.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: CLND-350-38-1

Technical Specifications

• Bolt Size: 3/8"
• Component: Compression Lug
• Manufacturer: Ilsco
• Material: Copper
• Connector Finish: Tin
• Conductor Type: Stranded
• Wire Gauge: 350 MCM
• Mounting: 2-Hole
• Stud Size: 3/8 in
• Allowable Gauge Range: 350
• Manufacturer Part Number: CLND-350-38-1
• Product Series: CLND
• Family Series: Ilsco Terminals, CLND Series
• Description: CU CMP 350 kcmil 13/32-1 T UL CSA
• Wire Size Range: 3/0 AWG-350 kcmil
• Number of Conductors: 1
