ILSCO CLND-350-12-134 Surecrimp Copper Compression Lug, Conductor Size 350, 2 Holes, 1/2in Bolt Size, 1-3/4in Hole Spacing

Product Description

The ILSCO CLND-350-12-134 is a copper compression lug designed for use with conductors of size 350 KCMIL. It features two holes for mounting, each with a bolt size of one-half inch and a hole spacing of one and three-quarters inches. The long barrel design allows for easy conductor insertion and is suitable for various electrical connections.

• Constructed from seamless copper tubing for high conductivity
• UL and CSA certified for safety and reliability
• Chamfered entry for simple installation

Product Highlights

This compression lug is ideal for high voltage applications up to thirty-five thousand volts when proper spacing and insulation techniques are used. It provides excellent crimping characteristics and low contact resistance, making it a versatile choice for electrical projects.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Brand: ILSCO

Technical Specifications

• Catalog Number: CLND-350-12-134
• Conductor Material: Copper
• Barrel Length: 2 inches
• Pad Hole Spacing: 1-3/4 inches
• Stud Size: 1/2 inch
• Cross Reference Products: 3M 31156, ABBInstall 54280, Burndy YA28-2LN
• Country of Origin: Mexico
• UPC: 783669643909
