Ilsco CLND-3-14-58 Copper Compression Lug, 3 AWG, 2-Hole, 1/4 in Bolt Size

Product Description

The Ilsco CLND-3-14-58 is a reliable copper compression lug, designed for high-performance electrical connections. This connector is UL/CSA listed and suitable for use with three AWG copper conductors. It features two mounting holes with a spacing of five-eighths inches and is compatible with a quarter-inch bolt size.

• Constructed from copper with electro-tin plating for enhanced corrosion resistance.
• Rated for voltage up to thirty-five kV, ensuring safety and reliability.
• Designed for direct burial and suitable for stranded or flex conductor types.

Product Highlights

Ideal for electrical applications requiring robust and durable connections, especially in challenging environments.

Product Information

Standard Information

• Brand: Ilsco
• Sub Brand: Surecrimp

Technical Specifications

• Catalog Number: CLND-3-14-58
• Conductor Size: 3 AWG
• Overall Length: 2.817 inches
• Barrel Length: 1.125 inches
• Mounting Hole Size: 0.281 inches
• Mounting Hole Spacing: 0.625 inches
• Number of Holes: 2
• Voltage Rating: 35 kV
• Material: Copper
• Color Coding: White
• Temperature Rating: 90 degrees C
• Connection Type: Compression
• Weight: 0.041 lb
• Inside Diameter: 0.275 inches
• Outside Diameter: 0.375 inches
• Die Index: I-29
