Ilsco CLND-3/0-38-1 SureCrimp Copper Compression Lug 3/0, 2 Holes, 3/8in Bolt Size

Product Description

The ILSCO CLND-3/0-38-1 SureCrimp® Copper Compression Lug is made from copper and tin plated. This long barrel, standard tang lug has 2 mounting holes and a 3/8in bolt size with 1in hole spacing. It is UL 486A/B Listed, UL 467 Listed and C22.2 No. 65-03 certified. Rated for 35 kV.

• Copper Compression Lug
• Tin plated connector
• Long barrel

Product Highlights

The ILSCO CLND-3/0-38-1 copper compression lug is ideal for electrical connections requiring a secure and corrosion-resistant termination.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: CLND-3/0-38-1
• Country of Origin: Unknown

Technical Specifications

• Applications: Copper Compression Lug
• Barrel Length: 1.5 in
• Barrel Type: Long
• Bolt Size: 3/8 IN
• Color Coding: Orange
• Conductor Material: Copper
• Conductor Type: Flex,Stranded
• Connection Type: Compression
• Direct Burial?: Yes
• Material: Copper
• Mounting Hole Size: 0.406 in
• Number of Holes: 2 Hole
• Temperature Rating: 90 degrees C
• Type: CLND:2 HOLE LONG BARREL
• Voltage: 35 kV
• Brand: Ilsco
• Sub Brand: Surecrimp
• Color: Silver
• Height: 0.649 Inch
• Inside Diameter: 0.484 in
• Length: 3.876 Inch
• Outside Diameter: 0.609 in
• Width: 0.885 in
• ECCN: EAR99
• UNSPSC: 39121448
• Manufacturer Catalog Number: CLND-3/0-38-1
• Manufacturer Part Number: CLND-3/0-38-1
• Manufacturer: Ilsco
• Product Series: CLND
• Family Series: Ilsco Terminals, CLND Series
• Description: CU CMP 3/0 AWG 13/32-1 T UL C SA
• Wire Size Range: 2-3/0 AWG
• Stud Size: 3/8 "
• Number of Conductors: 1
