ILSCO CLND-3/0-12-134 Surecrimp Copper Compression Lug, Conductor Size 3/0, 2 Holes, 1/2in Bolt Size, 1-3/4in Hole Spacing

Product Description

The ILSCO CLND-3/0-12-134 is a copper compression lug designed for conductor sizes of three-aught AWG with two holes for secure installation. This compression lug features a bolt size of one-half inch and a hole spacing of one and three-quarters inches. It is built for durability and performance in various electrical applications.

• Made from high-strength seamless copper for optimal conductivity.
• Long barrel design ensures excellent crimping performance.
• UL listed and CSA certified for safety and compliance.

Product Highlights

This compression lug is ideal for use in circuits rated up to thirty-five thousand volts when the proper insulation techniques are applied, making it suitable for a wide range of applications, including high-voltage connections.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Brand: ILSCO

Technical Specifications

• Catalog Number: CLND-3/0-12-134
• Material: Seamless electro-tin plated copper
• Conductor Size: 3/0 AWG
• Stud Size: 1/2 inch
• Pad Hole Spacing: 1-3/4 inch
• Barrel Length: 1.5 inches
• Color: Orange
• Die Index: I-50
• Voltage Rating: 600 VAC
• Temperature Rating: 90 degrees Celsius
• Approval: UL 453G, CSA LR-29601
