Ilsco CLND-250-12-134 SureCrimp Copper Compression Lug 35 Volt (250 kcmil, 2-Hole, 1/2 in Bolt)

Product Description

The ILSCO CLND-250-12-134 is a SureCrimp copper compression lug designed for terminating copper stranded conductors. It features a long 1.688 in barrel, tin electro-plated finish, and two 1/2 in mounting holes with 1.75 in hole spacing. The lug is listed to UL 486A/B and UL 467, CSA C22.2 No. 65-03, rated 90 degrees C, and is suitable for direct burial and grounding/bonding applications.

• Accepts copper stranded conductors up to 250 kcmil; compression connection; die index I-62 (yellow).
• Two mounting holes with 1/2 in stud size and 1.75 in (44.45 mm) hole spacing; overall length 5.219 in.
• Electro tin plated copper construction with long barrel (1.688 in); UL 486A/B, UL 467 and CSA certified; 90 degrees C temperature rating.

Product Highlights

Long-barrel tin-plated copper lug for 250 kcmil conductors, 2-hole 1/2 in stud mounting, UL/CSA listings, die index I-62.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: CLND-250-12-134
• Country of Origin: United States
