ILSCO ASN-3/0 Surecrimp Aluminum Compression Sleeve, Conductor Size 3/0, Tin Plated, UL, CSA

Product Description

ILSCO ASN-3/0 is a reliable compression sleeve designed for electrical connections. This aluminum compression sleeve is compatible with conductor sizes ranging from 1 to 3/0 AWG. The sleeve is electro-tin plated, which helps reduce contact resistance and ensures a secure connection.

• Manufactured from high-strength aluminum alloy
• Chamfered entry simplifies conductor insertion
• Pre-filled with DE-OX to prevent oxidation

Product Highlights

This compression sleeve is suitable for both aluminum and copper conductors and can be utilized in high voltage applications when proper installation techniques are employed.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: ASN-3/0
• Conductor Size: 1 to 3/0 AWG
• Connector Type: Crimp
• Material: Aluminum Alloy
• Length: 2.71 in
• Dimensions: 0.495 in ID x 0.761 in OD
• Finish: Electro-Plated Tin
• Temperature Rating: 90 deg C
• Mfg Standards/Approvals: ARRA Compliant|Buy American Act Compliant|UL 486A-B
