ILSCO ALND-400-12-134 Surecrimp Aluminum Compression Lug 400 Conductors 2 Holes 1-3/4 Hole Spacing

Product Description

The ILSCO ALND-400-12-134 is a compression lug designed for use with 400 kcmil conductors. This lug features two holes for mounting, with a bolt size of one half inch and a hole spacing of one and three fourths inches. The long barrel provides easier wire insertion and enhances the crimp quality. It is made of aluminum and is tin plated for corrosion resistance. This product is suitable for high voltage applications and meets UL and CSA standards.

• Conductor size of 400 kcmil
• Long barrel design for improved crimping
• Rated for 35 kV applications

Product Highlights

This aluminum compression lug is dual-rated for aluminum and copper conductors, ideal for electrical installations that require secure connections.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer: ECM Industries

Technical Specifications

• Catalog Number: ALND-400-12-134
• Country of Origin: Mexico
• UPC: 783669687637
• Length: 5.99 inches
• Width: 1.623 inches
• Height: 1.233 inches
• Weight: 0.357 lbs
