ILSCO ALND-350-12-134 Surecrimp Aluminum Compression Lug, Conductor Size 350, 2 Holes, 1/2in Bolt Size, 1-3/4in Hole Spacing, Long Barrel, No Sight Window

Product Description

The ILSCO ALND-350-12-134 is an aluminum compression lug designed for use with conductor size 350 KCMIL. This product features two holes for mounting, a half-inch bolt size, and a spacing of one and three-fourth inches for the holes. It is suitable for both copper and aluminum conductors, providing low contact resistance and ease of installation.

• Dual rated for aluminum and copper conductors
• Long barrel design for improved conductivity
• UL and CSA approved for safety

Product Highlights

Designed for application versatility, the ILSCO ALND-350-12-134 ensures reliable connections in various electrical applications. Its long barrel facilitates better performance and longer service life.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer: ECM Industries

Technical Specifications

• Catalog Number: ALND-350-12-134
• Material: Aluminum
• Conductor Size: 350 KCMIL
• Pad Hole Spacing: 1.188 Inch
• Stud Size: 1/2 Inch
• Barrel Length: 2.353 Inch
• Number Of Pad Holes: 2
• Approval: UL 453G, CSA
