ILSCO AK-4 Aluminum Split Bolt, Main Range 4-8, Tap Range 4-10, Tin Plated, UL, CSA

Product Description

The ILSCO AK-4 is an aluminum split bolt connector designed for connecting copper and aluminum conductors. It has a main range of four to eight and a tap range of four to ten. The connector is electro-tin plated and meets UL and CSA standards.

• Made from heat-treated aluminum alloy
• Features triangular edges to bite into conductors
• Includes hex head for easy installation

Product Highlights

This split bolt connector provides maximum conductivity and strength, ideal for electrical installations. The spacer bar feature prevents galvanic corrosion, making it suitable for different metal combinations.

Product Information

Standard Information

• Catalog Number: AK-4
• Manufacturer: ECM Industries
• Brand: ILSCO
• Country of Origin: United States
• UPC: 783669008319

Technical Specifications

• Maximum Run Conductor Size: 4 AWG Stranded
• Maximum Tap Conductor Size: 4 AWG Stranded
• Minimum Run Conductor Size: 8 AWG Solid
• Minimum Tap Conductor Size: 10 AWG Solid
• Material: Electro-Tin Plated Heat Treated Aluminum Alloy
• Installation: Hex Head Split Bolt with Spacer Bar
• Approval: UL 670B, CSA
• PDW ID: ECL61055
