ILSCO AK-350 Aluminum Split Bolt, Main Range 350-1/0, Tap Range 350-4

Product Description

The ILSCO AK-350 is an aluminum split bolt connector designed for connecting copper and aluminum conductors. It is suitable for primary applications in electrical systems. The connector supports a maximum run conductor size of 350 KCMIL and a tap range of up to 350 KCMIL.

• Compatible with both copper and aluminum conductors.
• Features a hex head design for easy installation.
• Manufactured from heat-treated aluminum alloy for enhanced conductivity.

Product Highlights

The ILSCO AK-350 provides reliable and efficient connections for electrical systems.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Country of Origin: United States

Technical Specifications

• Catalog Number: AK-350
• Maximum Run Conductor Size: 350 KCMIL (Compact)
• Minimum Run Conductor Size: 1/0 AWG Stranded (Compact)
• Maximum Tap Conductor Size: 350 KCMIL
• Minimum Tap Conductor Size: 4 AWG Stranded
• UPC: 783669008364
• Material: Electro-Tin Plated Heat Treated Aluminum Alloy
• Approval: UL 670B, CSA
