ILSCO AK-2/0 Aluminum Split Bolt, Main Range 2/0-2, Tap Range 2/0-8, Tin Plated, UL, CSA

Product Description

The ILSCO AK-2/0 is a reliable split bolt connector designed for use with both aluminum and copper conductors. This product is ideal for electrical connections in various applications.

• Dual Rated for Aluminum and Copper
• Electro-Tin Plated for Low Contact Resistance
• Hex Head for Easy Installation

Product Highlights

The split bolt design allows for secure connections, ensuring optimal conductivity. This connector is suitable for a variety of wire sizes.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Country of Origin: United States

Technical Specifications

• Catalog Number: AK-2/0
• Conductor Material: Aluminum/Copper
• Maximum Run Conductor Size: 2/0 AWG Stranded (Compact)
• Maximum Tap Conductor Size: 2/0 AWG Stranded
• Minimum Run Conductor Size: 2 AWG Stranded (Compact)
• Minimum Tap Conductor Size: 8 AWG Stranded
• Approval: UL 670B, CSA
• Material: Electro-Tin Plated Heat Treated Aluminum Alloy
