ILSCO AK-1/0 Aluminum Split Bolt, Main Range 1/0-2, Tap Range 1/0-8

Product Description

The ILSCO AK-1/0 is an aluminum split bolt connector designed for wire termination. This connector supports a main range of one over zero to two American Wire Gauge (AWG) and a tap range of one over zero to eight AWG. This product is manufactured to deliver reliable connections in electrical applications.

• Designed for aluminum and copper conductors
• UL and CSA approved for safety
• Electro-tin plated for low contact resistance

Product Highlights

This connector features a hex head design for ease of installation, along with a spacer bar that separates dissimilar metals to avoid galvanic corrosion.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer: ECM Industries

Technical Specifications

• Catalog Number: AK-1/0
• Country of Origin: United States
• Material: Electro-Tin Plated Heat Treated Aluminum Alloy
• Maximum Run Conductor Size: 1/0 AWG Stranded (Compact)
• Minimum Run Conductor Size: 2 AWG Stranded (Compact)
• Maximum Tap Conductor Size: 1/0 AWG Stranded
• Minimum Tap Conductor Size: 8 AWG Stranded
• UPC: 783669008333
