Ilsco ACM-750 Aluminum Compression Pigtail Adaptor 750 kcmil

Product Description

The ILSCO ACM-750 is an aluminum compression pigtail adaptor designed for conductor sizes 750 kcmil - 700 kcmil. Constructed from high-strength aluminum alloy, it features a tin-plated connector and is supplied with an insulating cover. This adaptor is UL 486A/B Listed and CSA certified, ensuring reliability for aluminum or copper conductors.

• Dual rated for aluminum and copper conductors
• Features a knurled pin for greater surface contact
• Prefilled with DE-OX® oxide inhibiting compound

Product Highlights

Aluminum compression pigtail adaptor with tin-plated connector and insulating cover. Ideal for terminating connectors.

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: ACM-750
• Country of Origin: MX - Mexico

Technical Specifications

• Conductor Type: Stranded
• Barrel Marking: Ink
• Barrel Type: Standard
• Connecting Angle: 180
• Connection Type: Compression
• Contains DE-OX®: Yes
• Flared End: No
• ILSCOs Die Index Number: 18
• Number of Conductors: 1
• Replacement Part(s): Cover
• Conductor Material: Aluminum, Copper
• Connector Finish: Tin
• Insulation: Supplied with insulating cover
• Material: Aluminum
• Temperature Rating: 90 degrees C
• Voltage Rating: 600 V
• Voltage Rating without cover: 35 kV
• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
• UL Control Number: 941R
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E62525
• Barrel Length (IN): 2.03
• Barrel Length (mm): 51.562
• Cover Length (IN): 3.33
• Cover Length (mm): 84.582
• Height (IN): 1.64
• Height BX (IN): 2
• Height (mm): 41.656
• Inside Diameter (IN): 1.03
• Inside Diameter (mm): 26.162
• Length (IN): 5.005
• Length (mm): 127.127
• Mounting Hole Spacing (mm): 0
• Outside Diameter (IN): 1.46
• Outside Diameter (mm): 37.084
• Pin Diameter (IN): 0.784
• Pin Diameter (mm): 19.9136
• Pin Length (IN): 1.76
• Pin Length (mm): 44.704
• Weight (LB): 0.393
• Weight BX (LB): 2.154
• Width (IN): 1.64
• Width BX (IN): 6.1875
• Width (mm): 41.656
• Approximate Pin Size: 500 kcmil
• Conductor Range AL Stranded (Primary, run, main, line): 750 kcmil - 700 kcmil
• Conductor Range CU Solid (Primary, run, main, line): NA
• Conductor Range CU Stranded (Primary, run, main, line): 750 kcmil - 700 kcmil
• Conductor Range AL Solid (Primary, run, main, line): NA
• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 3
• Dual Rated: Yes
• NEMA Code: S-588-3
• Applications: Terminating Connector
• Barrel Length: 2.03 in
• Color Coding: Yellow
• Conductor Size: 700-750 kcmil
• Contact Material: Aluminum
• Size: L:5.005;W:1.64;H:1.64 IN
• Standard: UL Specifications: UL 486A-B,CSA File Number: LR-29601,UL File Number: E62525
• Type: Long, Round
• Voltage: 600 Volt
• Brand: Ilsco
• Sub Brand: ClearChoice
• 12-Digit UPC: 783669009286
• Product UPC: 78366900928
• Height: 1.64 Inch
• Inside Diameter: 1.03 in
• Length: 5.005 Inch
• Outside Diameter: 1.46 in
• Width: 1.64 in
• Diameter: 0.998 in
• Allowable Gauge Range: 750
• Plug Diameter: 0.81 in.
• ECCN: EAR99
• UNSPSC: 39121448
• Country of Origin: United States
