IGNITION CONTROL 24VAC 50/60HZ G770KHA2 for Johnson Controls JOHG770KHA2

Product Description

This item for Johnson Controls G770KHA2 is an ignition control designed for reliable operation in HVAC systems.

• Compatible with natural and LP gas.
• Functions at 24VAC and 50/60Hz.
• Features an intermittent pilot ignition system.

Product Highlights

This ignition control unit is essential for managing burner operations effectively. It includes connections for multiple inputs and outputs, ensuring compatibility with various HVAC setups.

Product Information

Standard Information

• Weight: 1

Technical Specifications

• Dimensions: 5.5 inches x 4.3 inches x 3.5 inches
• Current Draw: 0.2 amp
• Pilot Voltage: 1 amp max
• Magnetic Valve Voltage: 2 amp max
• Trial Time: 8 seconds
• Inter-Purge Time: 15 seconds
• Connections: 1 MV, 2 MV/PV, 3 PV, 4 GND (burner), 5 GND, 6 24V, 7 TH, 8 SENSE, 9 INTERNAL, 10 SPARK WIRE 1/4
