IDEC RU4S-A24 Electromechanical Relay 24VAC 164Ohm 6A 4PDT 27.5x21x41.6 mm Socket General Purpose Relay 5 Items

Product Description

The IDEC Electromechanical Relay RU4S-A24 is a versatile and reliable relay. This relay features a 4PDT (four-pole double-throw) contact form, making it suitable for a wide range of applications. The relay operates at 24VAC with a coil resistance of 164 ohms and a current rating of 6 amps. The relay's dimensions are 27.5 x 21 x 41.6 mm.

• 4PDT contact form
• 24VAC coil voltage
• Compact design with integrated lever

Product Highlights

IDEC's RU Series relays are designed for industrial applications. They offer reliable performance with features like a mechanical flag indicator and a manual latching lever. The relay is lead-free and cadmium-free, ensuring it is environmentally friendly.

Product Information

Standard Information

• Brand: IDEC
• MPN: RU4S-A24

Technical Specifications

• Type: Universal
• Series: RU Series
• Dimensions: 27.5 x 21 x 41.6 mm
• Coil Voltage: 24 VAC
• Contact Form: 4PDT
• Power Rating: 1.1 to 1.4 VA at 50 Hz / 0.9 to 1.2 VA at 60 Hz
• Terminal Type: Plug-In/Blade
• Contact Rating: 6 A
• Number of Pins: 14
• Amperage Rating: 6 A
• Number of Poles: 4
• Frequency Rating: 50/60 Hz
• Temperature Rating: -55 to 60 degrees Celsius
• Standards/Approvals: CE EN61810-1, CSA/cURus Certified, EN Compliant, TUV Approved, UL Listed
