IDEC RU2S-A24 DPDT 10A 24VAC Relay

Product Description

The IDEC RU2S-A24 is a universal DPDT relay designed for robust performance in industrial applications. It operates with a 24 VAC coil and supports up to 10 amperes switching current, suitable for a diverse range of uses including automation, HVAC systems, and lighting control.

• Compact and efficient design ensures optimal performance with minimal space requirements.
• Features a manual latching lever and a green indicator LED for operational status at a glance.
• Constructed with environmentally conscious materials, lead-free and cadmium-free contacts.

Product Highlights

This relay offers 50 million mechanical operations indicating high durability. Its solder-free construction along with silver alloy contact material enhances reliability and longevity.

Product Information

Standard Information

• Brand: IDEC
• MPN: RU2S-A24
• Series: RU Series

Technical Specifications

• Amperage Rating: 10 A
• Coil Voltage: 24 VAC
• Contact Form: DPDT
• Contact Rating: 250 VAC/30 VDC
• Number of Pins: 8
• Number of Poles: 2
• Temperature Rating: -55 to 70 deg C
• Mounting Type: Socket
• Terminal Type: Plug-In
• Standards/Approvals: UL Listed, CSA Certified, EN Compliant
