IDEC RH2B-UAC220-240V Power Relay DPDT 240VAC 10A Plug-In

Product Description

The IDEC RH2B-UAC220-240V is a DPDT power relay designed for robust performance in industrial applications. Efficiently switching electrical loads, this relay is commonly used for controlling motors, lights, and other heavy-duty equipment.

• Dual pole dual throw configuration ensures versatile application.
• Rated for 220 to 240 volts AC, suitable for substantial electrical setups.
• Compact dimensions and blade terminals offer easy installation and reliable connections.

Product Highlights

This power relay by IDEC features a compact design that does not compromise on the power capacity, capable of handling up to 10A with AC voltages between 220 and 240V. The blade terminal connections ensure a secure fit and consistent performance.

Product Information

Standard Information

• Brand: IDEC
• MPN: RH2B-UAC220-240V

Technical Specifications

• Contact Configuration: DPDT
• Voltage Rating: 220 to 240 VAC
• Current Rating: 10 A
• Number of Poles: 2
• Temperature Range: -30 to 70 degrees Celsius
• Compliance: CSA, CE, cRUus, TUV
• Mounting Type: Socket
• Terminal Type: Blade
