IDEC PS5R-VB12 PS5R-V Switching Power Supply 12VDC 15W

Product Description

The IDEC PS5R-VB12 is a switching power supply designed for effective voltage distribution. This model delivers a twelve VDC output voltage and supports a maximum output current of 1.3 amps. With input voltage capabilities ranging from one hundred to two hundred forty VAC, it can be utilized in various applications.

• Compact size saves panel space.
• Wide operating temperature range ensures reliable performance.
• RoHS compliant and approved for Class I and Division 2 hazardous locations.

Product Highlights

The PS5R-VB12 power supply can be installed in six directions, providing flexibility in unit placement. It is built with spring-up terminals that accept ring and fork terminals, enhancing convenience during installation.

Product Information

Standard Information

• Brand: IDEC
• Part Number: PS5R-VB12

Technical Specifications

• Input Voltage: 85-264 VAC, 100-370 VDC
• Output Voltage: 12 VDC
• Output Current: 1.3 A
• Output Power: 15 W
• Mounting: DIN Rail
• Isolation: Isolated
