Ideal Industries 89-208 Terminal Strip 30A 600V (Box of 10)

Product Description

The Ideal Industries 89-208 is a terminal strip designed for robust electrical connections. This 8-circuit terminal strip supports a maximum current of thirty amps and a voltage of six hundred volts. The construction features a polyester thermoplastic base which enhances durability and resistance to breakage.

• Accepts wire sizes from ten to twenty-two AWG.
• Center spacing measures zero point five six two inches.
• Corrosion-resistant screws included.

Product Highlights

Rugged and reliable, this terminal strip is suitable for various applications in power distribution.

Product Information

Standard Information

• Manufacturer: Ideal Industries
• Part Number: 89-208

Technical Specifications

• Amperage Rating: 30 Amp
• Voltage Rating: 600 Volt
• Wire Size Range: 22-10 AWG
• Center Spacing: 0.562 inches
• Torque Rating: 16 in-lb
• Material: Polyester Thermoplastic
• Mounting Type: Surface
• Temperature Rating: -40 to 260 degrees Fahrenheit
