Ideal 89-408 Terminal Strip 250 V 8-Pole

Product Description

The IDEAL 89-408 terminal strips are designed for ruggedness, reliability, and ease of use. Features a thermoplastic base and corrosion-resistant screws and hardware for extended service life. It is available in a wide variety of circuit configurations and electrical ratings. Rated to 250V and accepts #22 to #12 AWG wire.

• Torque Rating of 9 in-lbs
• Rugged base eliminates breakage
• Center spacing 0.437 IN (11.1 mm)

Product Highlights

The IDEAL terminal strip offers convenient and versatile application with accessory hardware providing a variety of termination options.

Product Information

Standard Information

• Brand: IDEAL
• Manufacturer Part Number: 89-408
• Country of Origin: United States

Technical Specifications

• Catalog Number: 89-408
• Manufacturer: Ideal Industries
• Brand: Ideal
• Country of Origin: United States
• Made in USA: Yes
• Amperage Rating: 20
• Material: Zinc-Plated Steel Screw
• Special Features: Features: Torque Rating of 9 in-lbs; Rugged base eliminates breakage; Center spacing 0.437 IN (11.1 mm); Accepts #22 to #14 AWG wire; Corrosion resistant surface plates w/ #6-32 philslot screws; Rated to 250V, 20A; Accessory jumpers available; Heavy-duty, corrosion-resistant screws, surface plates and optional hardware; Accessory hardware provides a variety of termination options; Available cover helps prevent contact with live terminals; Rugged polyester thermoplastic base (UL Rated 94V-0); Operating temperature rated from 130 Degrees C (260 Degrees F) to -40 Degrees C (-40 Degrees F); UL Recognized (E62622) and CSA Certified (LR15364).; Number Of Circuits: 8; Torque Rating: 9 IN-LB; Terminal Screw Size: 8
• Standard: CSA, UL Listed, RoHS
• RoHS URL: https://www.ideadigitalcontent.com/files/11020/US_ROHS_COMPLIANCE_STATEMENT_REV_2_23_2015.PDF
• UPC: 783250894086
• GTIN: 00783250894086
• Voltage Rating: 250
• Wire Size: 22 - 12 AWG
• ADI Part Number: IL-89408
• Packaged Quantity: 1
• Product Line: Wire Termination
• Product Series: Terminal Strips
• Product Type: Wire Block
• Centre spacing: .437" (11.10mm)
• Accepts wire sizes: 12 through 22 AWG Cu
• Terminal screws: #6-32 Philslot, zinc-plated steel
• Base: Rugged polyester thermoplastic base (UL Rated 94V-0)
• Operating temperature: Rated from 130 C (260 F) to -40 C (-40 F)
• Recommended torque: 9 in-lb
• UL: Recognized (E82048)
• CSA: Certified (LR15364)
• ECCN: EAR99
• UNSPSC: 39121407
• Material : Zinc Plated Steel
• Mfr Part #: 89-408
• Condition: NEW
