Ideal 30-451J Wing-Nut Wire Connector, Twist-On, 225 Count

Product Description

The Ideal 30-451J Wing-Nut Wire Connector provides reliable connections for wiring applications. This connector is designed for conductor sizes ranging from eighteen to ten AWG. It can accommodate a combination of two to six conductors, making it suitable for a wide range of electrical tasks.

• Flame-retardant shell ensures safety in electrical environments.
• Live-action spring allows flexibility and adaptability in wire combinations.
• No pre-twisting is necessary for secure connections.

Product Highlights

This connector features a contoured wing design for better grip and torque during installation, facilitating an efficient electrical job.

Product Information

Standard Information

• Brand: Ideal
• MPN: 30-451J

Technical Specifications

• Color: Yellow
• Wire Size: 18 to 10 AWG
• Voltage Rating: 600 VAC
• Temperature Rating: 221 degrees F
• Material: Polypropylene
• Dimensions: 0.48 in Dia x 1.015625 in W x 0.6875 in H
• Number of Conductors: 1 to 6
• Environmental Conditions: Tough, UL 94V-2 Flame-Retardant Shell
