Ideal 30-292 Greenie Grounding Wire Connector 600V

Product Description

The IDEAL 30-292 Greenie Grounding Wire Connector features a contoured winged, twist-on shell style and a live action, square wire spring. Designed for making ground connections and bonding non-metallic sheathed cable. It accommodates solid or stranded copper wire from 14 to 10 AWG and is rated for up to 600 VAC.

• Designed for making ground connections and bonding non-metallic sheathed cable
• Contoured wings for maximum leverage
• Live action, square wire spring provides superior grounding connections

Product Highlights

This connector provides an easy, secure grip for connecting a wide range of wires and can be reused on same size or larger combinations.

Product Information

Standard Information

• Brand: IDEAL
• Manufacturer Part Number: 30-292
• Country of Origin: United States

Technical Specifications

• Series: 92®
• Shell Style: Contoured Winged/Twist On
• Spring Type: Live Action/Square Wire
• Wire Type: Solid/Stranded Copper
• Wire Size: 14 to 10 AWG
• Voltage Rating: 600 V
• Temperature Rating: 221 deg F
• Manufacturer: Ideal Industries
• Number of Conductors: 2 to 5
• Standard: CSA Certified to C22.2 #188, UL Listed to 467, complies with Federal Specification W-S-610E, RoHS Compliant
• Country of Origin: United States
• Made in USA: Yes
• Application: Insulating or Joining 2 or more grounding or bonding conductors
• Environmental Conditions: Tough, UL 94V-2 Flame-Retardant Shell Rated At 105 DEG C (221 F)
• Termination Method: Twist-on
• Maximum Temperature: 221°F (105°C)
• Maximum Wire Gauge: 10 AWG
• Minimum Wire Gauge: 14 AWG
