IDEAL 2006 Coupling Heavy Duty Stainless Steel No-Hub 2

Product Description

The IDEAL 2006 is a heavy-duty coupling made from stainless steel designed for no-hub applications. This coupling provides a secure and reliable connection for pipes with a nominal size of two inches.

• Constructed with a molded one-piece elastomer sealing sleeve.
• Features four stainless steel bands for enhanced load distribution.
• Corrosion-resistant and suitable for both above and below ground applications.

Product Highlights

This coupling is ideal for non-potable waste systems, offering durability and ease of installation.

Product Information

Standard Information

• Manufacturer: IDEAL
• Part Number: 659522

Technical Specifications

• Nominal Pipe Size: 2 inches
• Width: 3 inches
• Minimum Tensile Strength: 1500 PSI
• Elongation: 250%
• Durometer (Shore A): 70 ± 5
• Compression Set: 15% max. after 22 hours at 158°F
• Oil Immersion: 80% max. volume change after immersion in TRM oil #3 for 70 hours at 212°F
• Tear Resistance: Die C 150 lbs. max/inch of thickness
• Water Absorption: 20% max. by weight after 7 days at 158°F
