IDC Select IDCSD-40MM Finished Bore QD Bushing 40 mm Dia Bore

Product Description

IDC Select IDCSD-40MM is a finished bore QD bushing that is suitable for various industrial applications. It has a bore diameter of forty millimeters and a barrel diameter of two point one eight seven inches. The flange diameter is three and one eighth inches, with an overall length of one and thirteen sixteenth inches. It is made from nodular graphite cast iron.

• Compatible with both inch and metric sizes.
• Easy to install with a screws over keyway feature.
• Interchangeable with industry standard designs.

Product Highlights

This product is ideal for air handling, mining, and agricultural applications.

Product Information

Standard Information

• Brand: IDC Select
• Manufacturer: IDC Select

Technical Specifications

• Type: Finished Bore
• Material: Nodular Graphite Cast Iron
• Bore Diameter: 40 mm
• Barrel Diameter: 2.187 in
• Flange Diameter: 3-1/8 in
• Overall Length: 1-13/16 in
• Torque Rating: 6 ft-lb
• Includes: (3) Cap Screws
