Icp evd5x25m14a EVD5X 2-ton Cased Vertical Evaporator Coil

Product Description

The INTERNATIONAL COMFORT PRODUCTS evd5x25m14a is a cased vertical aluminum V-evaporator coil from the EVD5X Series, rated at 24,000 BTU/h (2 tons) and designed for use with R-454B refrigerant. The aluminum construction keeps coil weight low and resists corrosion over long service intervals. At 14 inches, this coil fits into standard cased vertical air handler configurations. The unit is A2L refrigerant compatible, making it appropriate for systems transitioning to lower-GWP refrigerants under current regulatory guidelines. Licensed HVAC technicians handle installation and refrigerant work on this coil.

This evaporator coil is suited for residential split-system cooling applications where a cased vertical coil position is required. The EVD5X Series is built for new installations and matched-system replacements where R-454B is the specified refrigerant. The 14-inch cabinet width targets common residential air handler footprints. Installers should verify system tonnage, refrigerant type, and cabinet dimensions against the equipment schedule before ordering.

Key Features

• Rated at 24,000 BTU/h (2 tons) for residential cooling capacity
• Compatible with R-454B, an A2L low-GWP refrigerant
• Aluminum coil construction for corrosion resistance and reduced weight
• Cased vertical orientation for standard upflow and downflow air handler installations
• V-coil configuration provides increased face area within a compact cabinet
• 14-inch cabinet width fits common residential air handler openings

Compatibility

Designed as an OEM-style replacement or new-installation evaporator coil for residential split-system air conditioners and heat pumps using R-454B refrigerant in a cased vertical coil configuration.

Installation Notes

Installation must be performed by an EPA Section 608 certified HVAC technician due to refrigerant handling requirements for A2L refrigerants. Disconnect and lock out all electrical power and shut down the refrigerant circuit before opening the system. Verify that all components in the system, including the condensing unit and line sets, are rated and approved for use with R-454B before charging. Follow current ASHRAE 15, local mechanical codes, and the equipment manufacturer instructions for coil installation, brazing procedures, and leak testing.

Technical Specifications

• Product Type: Evaporator Coil
• Series: EVD5X
• Capacity: 24,000 BTU/h
• Tonnage: 2 Tons
• Refrigerant: R-454B
• A2L Compatible: Yes
• Coil Material: Aluminum
• Cabinet Width: 14 inches
• Orientation: Cased Vertical
• Coil Configuration: V-Coil

Standard Information

• Brand: INTERNATIONAL COMFORT PRODUCTS
• Manufacturer Part Number: evd5x25m14a
