ICM Controls T8-RF210 120MM AC Axial Fan

Product Description

The ICM Controls T8-RF210 is a reliable 120mm AC axial fan ideal for various cooling and ventilation tasks. This fan operates at 115 Volts and provides an airflow of 106 CFM at a speed of 3000 RPM. The design includes a die-cast aluminum housing and a metal impeller, ensuring durability for long-term use. The shaded pole motor features impedance protection, which helps maintain fan performance.

• Operates at 115 Volts with a power consumption of 22 Watts.
• Ball bearing design offers smooth operation and increases lifespan.
• Simple terminal connection simplifies wiring for easy installation.

Product Highlights

This fan suits various general-purpose applications, making it a versatile choice for HVAC and ventilation projects.

Product Information

Standard Information

• Fan Type: AC Axial Fan
• Voltage: 115V

Technical Specifications

• Power: 22W
• Airflow: 106 CFM
• Speed: 3000 RPM
• Bearing Type: Ball Bearing
• Impeller Material: Metal
• Noise Level: 50 dB(A)
• Motor Type: Shaded Pole
• Housing Material: Die-cast Aluminum
• Dimensions: 120mm x 120mm x 38mm
