ICM Controls ICM517A-LITE Single-Phase Surge Protector

Product Description

The ICM Controls ICM517A-LITE is a Type 2 Surge Protective Device designed for single-phase applications. This surge protector safeguards equipment from voltage spikes and transient power surges. Ideal for motors, electronics, air conditioning systems, appliances, and refrigeration units, it is a crucial component for reliable electrical systems.

• Protects against voltage spikes and transient power surges.
• Suitable for both indoor and outdoor installation with a NEMA Type 4X enclosure.
• Compatible with single-phase 120/240V systems.

Product Highlights

This surge protector features a green light indicator to show active surge suppression, providing peace of mind for users.

Product Information

Standard Information

• Brand: ICM Controls
• Type: Surge Protective Device

Technical Specifications

• Service Voltage: 120/240 volt, single phase
• Maximum Surge Current: 100,000 amps
• Maximum Energy Dissipation: 1,020 Joules
• Installation Point: Electrical panel, electrical disconnect
• Diagnostics: Green light indicates surge suppression is present
• AC Protection Modes: L-L, L-N, L-G, N-G
• Conduit Connection: 3/4 inch
• Enclosure: NEMA Type 4X waterproof enclosure
• NEMA Rating: 4X
• Material: Aluminum
• Country/Region of Manufacture: United States
• Item Depth: 1.75
• Item Width: 2.25
• Item Height: 3.75
