Icm Controls ACH075 Temp Stat CI Only 18-30 VAC (75 Fixed) Replaces SC075

ICM CONTROLS
Brand: ICM CONTROLS
SKU: ACH075
Availability: In Stock

Ships same day if ordered by 12 pm
$24.64
$24.64
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Icm Controls ACH075 is a fixed setpoint temperature stat configured for CI only operation with a 75 F cooling setpoint. The ACH075 is intended for temporary dryout and construction cooling applications and provides a dry contact output for simple control use. Typical electrical characteristics include 18-30 VAC input and a maximum 2 amp switching output suitable for low ambient cutoff or condenser fan control.

  • Fixed 75 F setpoint for cooling/dryout applications
  • CI only configuration with dry contact output; switch closes above 75 F and opens below 75 F
  • Two-wire installation; 18-30 VAC input and 2 amp maximum output

Product Highlights

Fixed 75 F temporary cool-only thermostat for dryout and low ambient cutoff with 18-30 VAC input and 2 A output

Product Information

Standard Information

  • Brand: ICM CONTROLS
  • Manufacturer Part Number: ACH075
  • Country of Origin: United States
Technical Specifications
Brand
Icm Controls
MPN
ACH075
Type
Temperature stat / thermostat (fixed)
Operation
Cool-only, temporary dryout/construction
Mode
CI only (control input only)
Setpoint
75 F (fixed)
Input Voltage
18-30 VAC
Output Current
2 amp maximum
Wiring
2-wire
Accuracy
+/- 9 F
Switch Operation
Closes above 75 F; opens below 75 F
Temperature Range
45 F to 85 F (+/- 9 F)
Application
Dryout/construction; low ambient cutoff switch for condenser fan motor
Length
6 in
Replaces
SC075
