HYDROLEVEL 45-175 Safgard 170SV Low Water Cutoff w/ Auto Reset 120V

Product Description

The HYDROLEVEL 45-175 Safgard 170SV is a low water cutoff designed for hot water boilers. This unit has an automatic reset feature which allows it to restart the burner automatically when the water level returns to normal. The unit also includes contacts for an optional low-water alarm, enhancing safety while using hot water boilers.

• Automatic restart of burner when water level is normal
• Contacts for optional low-water alarm
• Heavy-duty construction for reliability

Product Highlights

This product is vital for maintaining safe operating conditions in hot water boilers.

Product Information

Standard Information

• Application: Hot Water Boilers
• Voltage: 120 VAC

Technical Specifications

• Power Consumption: 7 VA
• Switch Type: SPDT
• Max Pressure: 160 PSI
• Connection: 3/4 inch NPT
• Dimensions: 5.5 inches L x 6.25 inches W x 5.5625 inches H
• Pressure Rating: 250 PSI
• Standards/Approvals: UL Listed
• Actuation Type: Electronic
