Product Description
The HYDRO-RAIN PVCL-SFX-075 PVC-Lock Slide Repair Fitting is a push-fit fitting designed for repairing or installing PVC piped sprinkler systems without needing toxic glues or primers. It features a stainless steel retainer ring and an O-ring seal to prevent leaks. It reduces installation times and protects from harmful chemicals.
- No glue needed
- Easy push and go design
- Internal stainless Steel retaining ring
Product Highlights
This PVC-Lock fitting allows swiveling 360 degrees around the pipe for easy sprinkler head orientation and adjustment. It is suitable for all brands of Schedule 40 and 80, and Class PVC pipe.
Product Information
Standard Information
-
Brand: HYDRO-RAIN
-
Manufacturer Part Number: PVCL-SFX-075
-
Country of Origin: South Korea
Technical Specifications
-
Item Model Number: PVCL-SFX-075
-
Product Dimensions: 18 x 1.5 x 1.5 inches
-
Item Weight: 0.3 Pounds
-
Size: 3/4 in.
-
Material: Polyvinyl Chloride, Stainless Steel
-
Brand: Hydro-Rain
-
Connector Type: Slide
-
Thread Type: No Thread
-
Product Type: 3/4" PVC Lock Fittings
-
Series: PVC-Lock Slide Repair
-
Max Working Pressure: 150 PSI
-
Burst Pressure: 600 PSI
-
Working Pressure: 0-150 PSI
-
Warranty: 1 Year
-
Connection: PVC-Lock x Slip
-
Connection Type: Spigot
-
Dimensions: 18 in. x 1-1/2 in. x 1-1/2 in.
-
Weight: 0.3 lb.
-
Length: 18 in.
-
Connection 2 Size: 3/4 in.
-
Connection 2 Type: Spigot
-
Maximum Operating Pressure: 150 PSI
-
Item: Repair Fittings
-
Connection Size: 3/4 in.
-
Regulated: No
-
FITTING TYPE: SFX – Slide Fix (SOC x SPG)
-
COMPATIBLE PIPE MATERIAL: PVC
-
OPERATING PRESSURE RANGE: 0 to 150 PSI
-
FLOW RATE: 1 to 30 GPM
-
Country of Origin: South Korea
