Hunter XCH600 Xc Hybrid Controller, 6-station

Product Description

The HUNTER XCH600 XC Hybrid Controller effectively manages landscapes where electricity is unavailable. It operates DC-latching solenoids using solar energy, ambient light, or battery power. Ready for indoor or outdoor installations, this 6-station plastic model suits residential and commercial applications. 'Easy Retrieve' memory backup assures recall of watering programs.

• Operates DC-latching solenoids using solar energy, ambient light or battery power
• Features 'Easy Retrieve' memory backup
• Suitable for indoor and outdoor installations

Product Highlights

The HUNTER XCH600 XC Hybrid Controller delivers extensive power without the plug. Built with efficient water management features.

Product Information

Standard Information

• Brand: HUNTER
• Manufacturer Part Number: XCH600

Technical Specifications

• Number of Stations: 6
• Central Control: None (Standalone)
• Controller Power: Battery
• Field Valve Connection: Conventional wired
• Flow: Without Flow
• Network Connection Type: None
• Sensor Compatibility: Rain, Freeze, Wind, Soil Moisture
• Power Options: Ambient-Light-compatible Solar Panel (SPXCH Sold Separately), Battery (6 x AA Batteries), AC powered (526500 Sold Separately)
• Enclosure: Indoor/outdoor plastic
• independent programs: 3 with 4 start times each and up to 4-hour run time
• Electrical Specifications: Operates DC-latching solenoids (only) 9-11 VDC (even if powered by 24V AC transformer)
• Pump/master valve: Yes
• Sensor inputs: 1 (wired rain, freeze, or wind only)
• Operates on: solar panel (Sold Separately SPXCH, Battery Power (6 x AA Batteries) or optional 24 VAC plug-in wall adapter (Sold Separately 526500)
• Controller to solar panel: 100' maximum 18 AWG direct-burial wire
• Product Type: Standard Controllers
• Expandability: Fixed
• Power Source: Hybrid
• Number of Programs: 3
• Start Times Per Program: 4
• Max Station Run Time (HRS): 4
• Indoor: Yes
• Outdoor: Yes
• Rain Sensor Compatible: Yes
• Freeze Sensor Compatible: Yes
• Application: Residential|Light Commercial|Commercial
• Series: XCH
• Zones: 6
• Enclosure Type: Indoor/Outdoor
