Hunter HC50F50M HCV Check Valve 1/2-Inch

Product Description

The Hunter HC50F50M HCV Check Valve is an adjustable anti-drain valve designed to eliminate low-head drainage on sloped landscapes. Featuring 1/2" female inlet x 1/2" male outlet, it installs between the riser and sprinkler head. Constructed to schedule 80 specifications, making it durable and long-lasting. It provides reliable, adjustable shutoff for irrigation lines.

• Easily adjust to the proper check height and insert this remarkable product in between the riser and sprinkler head
• Adjustment access from top of valve
• Adjusts to compensate for elevational changes up to 32 ft.: Maximum flexibility

Product Highlights

The Hunter HCV prevents puddling and reduces water waste while offering dependable performance. Use with standard 1/2" irrigation risers.

Product Information

Standard Information

• Brand: HUNTER
• Manufacturer Part Number: HC50F50M

Technical Specifications

• Product Line: Accessories
• Product Model: HCV Check Valve
• SKU: HC50F50M
• Length: 3"
• Material: Sch. 80
• Exterior Finish: Plastic
• Inlet Connection Size: 0.5 Inches
• Inlet Connection Type: threaded
• Outlet Connection Type: NPT
• Number of Ports: 2
• Outlet Connection Size: 0.5 Inches
• Specification Met: ASME B16.34
• Connection: FPT
• Size: 1/2 in.
• Type: Drain Check
• Item: Valve
• Connection 2 Size: 1/2 in.
• Connection 2 Type: Mipt
• Regulated: No
• Brand Name: Hunter
• Flow Rate: 3 - 15 GPM
• Adjustable elevation: Top-access adjustment compensates for elevation changes from 4 to 32 ft (1.2–9.7 m)
• Durable construction: Manufactured to Schedule 80 specifications
• Compact size: Overall length approximately 3 in (76 mm)
