Johnson Controls HE-68N3-0N00WS System 450 Wall Mount Humidity and Temperature Transmitter

Product Description

The Johnson Controls HE-68N3-0N00WS System 450 Series provides a combined solution for monitoring both humidity and temperature, making it a versatile option for HVAC applications. Designed to replace previous System 350 and System 27 models, this transmitter ensures enhanced functionality with simplified setup.

• Supports up to three hard-wired input sensors for precise monitoring.
• Modular design with plug-together connectors allows for easy installation and flexibility in configuration.
• Features highly accurate nickel temperature sensors, ensuring reliability in diverse conditions.

Product Highlights

Equipped to function in a variety of conditions, from 0 to 55 degrees Celsius and 10 to 90% humidity, the Johnson Controls HE-68N3-0N00WS transmitter employs advanced technology to provide dual sensing capabilities. It features user-selectable humidity outputs and compatibility with multiple controllers, enhancing its usability in sophisticated systems.

Technical Specifications

• Manufacturer: Johnson Controls Inc
• Dimensions: 3-3/16 x 3-3/16 x 1-5/16 inches
• Voltage: 14 to 30V AC, 20 to 30V AC
• Connection: Screw Terminals
• Accuracy: ±3%
• Weight: 0.37 pounds
• Mount: Wall
• Output: 0 to 10 VDC
