Hubbell YS31L BURNDY CU BUTT SPLICE 350 MCM

Product Description

The Hubbell YS31L is a BURNDY HYLINK Compression Butt Splice designed for electrical applications. This splice connects conductors ranging from three hundred to three hundred fifty kcmil. It features a standard barrel construction and a length of two point six inches. The splice is compatible with tools for various conductor sizes and provides a reliable electrical connection.

• Connects three hundred to three hundred fifty kcmil conductors
• Standard barrel size of one point twelve inches
• Tin plated copper for durability

Product Highlights

This product features a center wire stop for proper conductor insertion, ensuring a secure fit.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78181050835

Technical Specifications

• Application: For limited space applications
• Barrel Size: 1.12 inches
• Color: Red
• Conductor Size: 3/0 AWG to 350 kcmil
• Finish: Tin Plated
• Length: 2.6 inches
• Material: Copper
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 486A-486B
• Temperature Rating: 90 degrees Celsius
• Voltage Rating: 600 to 35000 VAC
