Hubbell YS1CLBOX YS-L Standard Barrel Compression Butt Splice 1 AWG Conductor

Product Description

The Hubbell YS1CLBOX is a compression butt splice designed for use with stranded copper conductors. This tool is suitable for applications where space is limited.

• Compatible with 1 AWG conductors
• Voltage rating from six hundred to thirty-five thousand VAC
• Includes various tools and dies for effective use

Product Highlights

This splice is tin plated and meets multiple industry standards. It features a chamfered barrel for easy wire insertion.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78181055500

Technical Specifications

• Application: For limited space applications
• Barrel Size: 0.88 inches
• Color: Green
• Conductor Size: 1 AWG
• Conductor Type: Stranded Copper
• Finish: Tin Plated
• Length: 1.88 inches
• Manufacturer Part Number: YS1CLBOX
• Material: Copper
• Temperature Rating: 90 degrees C
• Voltage Rating: 600 to 35000 VAC
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 486A-486B
