Hubbell YHO1 BURNDY TAP CONN 1AWG ALCU

Product Description

Hubbell YHO1 is a BURNDY LOKTAP Compression Tap Connector. This tap connector is designed for 6 to 1 AWG main/run sizes and 6 to 1 AWG tap sizes. It accommodates a wide range of conductors, including ACSR, aluminum, and copper. The product features a durable aluminum construction and a figure H shape for effective electrical connections.

• Designed for copper, aluminum, or ACSR conductors
• Compatible with solid and stranded conductors
• Pre-filled with PENETROX for improved connection longevity

Product Highlights

The YHO1 connector provides reliable and efficient connections for electrical applications. It is suitable for street lighting and other industrial uses.

Product Information

Standard Information

• Application: For copper, aluminum or ACSR and compact conductors
• Conductor Type: ACSR/Aluminum/Copper/Solid/Stranded

Technical Specifications

• Manufacturer Part Number: YHO1
• Material: Aluminum
• Shape: Figure H
• Main Run Size: 6 to 1 AWG
• Tap Size: 6 to 1 AWG
• Dimensions: 1.35 in L x 1.11 in W x 0.67 in H
• Standards/Approvals: ARRA Compliant, RoHS Compliant, Buy American Act Compliant
• Specifications: O Element A Die Index, 0.162 to 0.26 in Tap Cable Dia, 0.162 to 0.332 in Run Cable Dia
