Hubbell YA302N YA30-2N BUR Copper Comp.Lug 300MCM With Two 1/2 Stud Holes

Product Description

The Hubbell YA302N is a compression lug designed for stranded copper conductors with a size of three hundred kcmil. This product serves as a reliable connection point in electrical installations, ensuring secure and long-lasting connections. Made from tin-plated copper, it supports voltages from six hundred VAC to thirty-five kV. The lug features two holes with a spacing of one and three-quarter inches, accommodating a half-inch stud size.

• Designed for standard tongue size of one point two inches wide by zero point sixteen inches thick
• Overall length measures five point sixty-four inches
• Temperature rating is up to ninety degrees Celsius

Product Highlights

This compression lug meets various safety standards, is RoHS compliant, and is ARRA compliant.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: YA302N

Technical Specifications

• Series: YA-2N
• Application: For code conductor
• Barrel Size: 2 in L
• Conductor Size: 300 kcmil
• Die Code: 17/298
• Material: Tin Plated Copper
• Voltage Rating: 600 VAC to 35 kV
• Temperature Rating: 90 deg C
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 468A/468B, CSA Certified
• Tongue Type: Standard
• Stud Size: 1/2 in
