Hubbell YA2C2N BURNDY 2 HOLE COMP LUG LNGBRL NO2-3 1/2B BRN CU

Product Description

The Hubbell YA2C2N is a BURNDY 2-Hole Compression Lug designed for use with 2 AWG stranded copper conductors. This compression lug supports a voltage rating of six hundred volts alternating current to thirty-five kilovolts direct current. It features a standard tongue shape and fits a half-inch stud, making it suitable for a variety of electrical applications. The overall length of the lug measures four point six four inches.

• Voltage rating of six hundred VAC to thirty-five kV
• Compatible with 2 AWG stranded copper conductors
• Overall length of four point six four inches

Product Highlights

This compression lug is compliant with ARRA and the Buy American Act. It is made from tin-plated copper for durability and has a temperature rating of ninety degrees Celsius.

Product Information

Standard Information

• Application: For code conductor
• Manufacturer: Hubbell

Technical Specifications

• Barrel Size: one and one-fourth inches long
• Color: brown
• Conductor Size: two AWG
• Die Code: ten
• Overall Length: four point six four inches
• Pad Size: zero point eighty-three inches
• Hole Spacing: one and three-fourth inches
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 468A/468B, CSA Certified, PROP65 Warning for lead compounds
• Stud Size: half inch
• Temperature Rating: ninety degrees Celsius
