Hubbell YA2C2LN BURNDY CULUG-2STR-SHORT-(2)NEMA 78181050076

Product Description

The Hubbell YA2C2LN is a BURNDY HYLUG Compression Lug designed for strong electrical connections. This product features a two-hole design suitable for a stranded copper conductor with a gauge of two AWG. The lug operates at voltages of six hundred VAC up to thirty-five kV, making it suitable for various applications.

• Compatible with multiple crimping tools including mechanical and hydraulic options.
• Made from high conductivity copper for efficient performance.
• Features a tin-plated finish for corrosion resistance.

Product Highlights

This product is built for reliability and can withstand temperature ratings up to ninety degrees Celsius.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: YA2C2LN

Technical Specifications

• Application: For code conductor
• Barrel Size: 0.88 inches long
• Color: Brown
• Conductor Size: 2 AWG
• Conductor Type: Stranded Copper
• Die Code: 10
• Material: Copper
• Overall Length: 4.27 inches
• Series: YA-2LN
• Stud Size: 1/2 inch
• Temperature Rating: 90 degrees Celsius
• Tongue Size: 0.83 inches wide x 0.12 inches thick
• Tongue Type: Standard/Straight
• Type: 2-Hole
• Voltage Rating: 600 VAC to 35 kV
