Hubbell YA29L4-BOX BURNDY COPPER COMP.LUG 250MCM W/3/8STUD HOLE

Product Description

The Hubbell YA29L4 features a compression lug designed for copper conductors. It is suitable for 250 kcmil stranded copper conductor applications. This product provides reliable connections in various electrical settings.

• Die code: 16
• Rated for voltages up to 35 kV
• Standard tongue size of 1.11 inches wide and 0.16 inches thick

Product Highlights

This compression lug is ideal for heavy industrial, utility, or commercial electrical applications. It simplifies cable preparation for secure terminations.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: YA29L4

Technical Specifications

• Application: For code conductor
• Barrel Size: 0.75 inches OD x 1.06 inches L
• Color: Yellow
• Conductor Size: 250 kcmil
• Conductor Type: Stranded Copper
• Die Code: 16
• Material: Copper
• Overall Length: 2.42 inches
• Series: YA-L
• Specifications: 0.41 inches stud hole spacing, 1-1/8 inches wire strip length, tin plated
• Standards/Approvals: ARRA Compliant | Buy American Act Compliant | CSA Certified | UL 467/467A/467B
• Stud Size: 3/8 inches
• Temperature Rating: 90 degrees Celsius
• Tongue Size: 1.11 inches W x 0.16 inches THK
• Tongue Type: Standard/Straight
• Type: 1-Hole
• Voltage Rating: 600 VAC to 35 kV
