Product Description
The Hubbell YA26LBOX is a 1-Hole compression lug designed for use with stranded copper conductors. It accommodates a conductor size of 2/0 AWG and features a die code of 13. This compression lug operates effectively at voltages ranging from six hundred volts to thirty-five thousand volts.
- Designed for stranded copper conductors.
- Suitable for use in a variety of electrical applications.
- Includes an inspection window for ease of installation verification.
Product Highlights
This product provides reliable electrical connections and is compliant with various industry standards.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
Manufacturer Part Number: YA26LBOX
Technical Specifications
-
Application: For code conductor
-
Barrel Size: 0.94 inches
-
Color: Black
-
Conductor Size: 2/0 AWG
-
Conductor Type: Stranded Copper
-
Die Code: 13
-
Material: Copper
-
Overall Length: 2.19 inches
-
Series: YA-L
-
Specifications: 1 inch wire strip, tin plated
-
Standards/Approvals: ARRA Compliant, Buy American Act Compliant, CSA Certified, RoHS Compliant, UL 467A/467B
-
Stud Size: 3/8 inches
-
Temperature Rating: 90 degrees Celsius
-
Tongue Size: 0.83 inches wide x 0.12 inches thick
-
Tongue Type: Standard/Straight
-
Type: 1-Hole
-
Voltage Rating: 600 VAC to 35 kV
