Hubbell YA252TC38 BURNDY CUHYLUG 1/0STR 2HOLE 3/8 YA252TC38

Product Description

The Hubbell YA252TC38 is a BURNDY HYLUG Compression Lug designed for connecting 1/0 AWG solid or stranded copper conductors. This lug features two holes, making it suitable for various electrical applications.

• Rated for voltages up to 35 kV.
• Includes a standard straight tongue design.
• Made from tin plated copper for enhanced conductivity.

Product Highlights

This compression lug is efficient for industrial and commercial electrical connections.

Product Information

Standard Information

• Manufacturer: Hubbell
• Product Number: YA252TC38

Technical Specifications

• Application: For code conductor
• Barrel Size: 0.51 inches OD x 1.38 inches L
• Color: Pink
• Conductor Size: 1/0 AWG
• Conductor Type: Solid/Stranded Copper
• Die Code: 12
• Material: Tin Plated Copper
• Overall Length: 3.62 inches
• Series: YA-2TC
• Standards/Approvals: UL 468A/468B Listed, CSA Certified, RoHS Compliant
• Stud Size: 3/8 inches
• Temperature Rating: 90 degrees C
• Tongue Size: 0.75 inches W x 0.12 inches THK
• Tongue Type: Standard/Straight
• Type: 2-Hole
• Voltage Rating: 600 VAC to 35 kV
