Hubbell YA1CL6BOX BURNDY 1STR CU 1-HOLE SHORT 1/2 78181055145

Product Description

The Hubbell YA1CL6BOX is a BURNDY HYLUG compression lug designed for reliable electrical connections. This component is suitable for 1 AWG stranded copper conductors with a 1/2 inch stud size. The product features a tin-plated copper body and is rated for voltages up to thirty-five kilovolts. It is a one-hole compression lug that meets various standards for safety and performance.

• 1 AWG stranded copper conductor
• Voltage rating of 600 VAC to 35 kV
• Chamfered standard barrel design

Product Highlights

The YA1CL6BOX offers an inspection window for visible connection status and is engineered for durability in various environmental conditions.

Product Information

Standard Information

• Manufacturer: Hubbell
• Manufacturer Part Number: YA1CL6BOX

Technical Specifications

• Application: For code conductor
• Barrel Size: 0.88 inches long
• Color: Green
• Conductor Size: 1 AWG
• Conductor Type: Stranded Copper
• Die Code: 11
• Material: Copper
• Overall Length: 2.37 inches
• Series: YA-L
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, CSA Certified, RoHS Compliant
• Stud Size: 1/2 inch
• Temperature Rating: 90 degrees Celsius
• Tongue Size: 0.73 inches wide x 0.09 inches thick
• Tongue Type: Standard/Straight
• Type: 1-Hole
• Voltage Rating: 600 VAC to 35 kV
