Hubbell Wiring Device-kellems USB15ACPDI Usb Receptacle

Product Description

The HUBBELL WIRING DEVICE-KELLEMS USB15ACPDI is a commercial-grade duplex receptacle with two integrated USB charging ports, designed for installation in standard outlet boxes. Rated at 15 amps and 125 volts with a NEMA 5-15R configuration, it delivers up to 1.5 amps of USB charging power per port. The unit supports USB PD 3.0 and USB BC1.2 charging protocols. Its tamper-resistant construction meets NEC Section 406.9 requirements. The ivory thermoplastic housing is built for commercial environments where durability and code compliance are non-negotiable. Electricians install this device as a direct replacement for standard duplex receptacles where device charging is needed at the outlet.

This receptacle is suited for commercial and light-industrial applications including offices, hospitality spaces, healthcare waiting areas, and multi-family residential units. It mounts in a standard outlet box using the included screw mounting hardware. The combination of AC receptacles and USB ports reduces the need for plug-in charging adapters at the outlet location, keeping face plates clean and circuits less cluttered. The power indicator provides a visual confirmation that the device is energized, useful during post-installation verification.

Key Features

• Dual USB ports with 1.5A charging power output, supporting USB PD 3.0 and USB BC1.2 protocols
• 15A, 125V AC duplex receptacle with NEMA 5-15R configuration
• Tamper-resistant design meets NEC Section 406.9 requirements
• Power indicator light confirms energized status
• Wiring options include back wiring and side terminal screws for installation flexibility
• Commercial-grade thermoplastic housing rated for outlet box mounting

Compatibility

Designed as an OEM-style replacement or upgrade device for standard single-gang outlet boxes in commercial electrical installations requiring integrated USB charging capability.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize the circuit at the breaker panel and verify the absence of voltage with a meter before beginning work. The device accepts back wiring or side terminal screw connections — follow the wiring method appropriate to the existing circuit conductors. Do not exceed the 15A circuit rating of the device.
