Hubbell Wiring Device-Kellems L1620P HWD 3-Phase Grounding Standard Sized Cord Mount Locking Male Plug 480 VAC 20 A L16-20P

Product Description

The Hubbell Wiring Device-Kellems L1620P is a reliable locking male plug designed for power connection applications in commercial and industrial settings. This plug operates at 480 VAC and is rated for 20 amperes. It features a three-pole, four-wire configuration which is essential for ensuring safe electrical connections. The plug is constructed from robust materials that can withstand harsh environmental conditions.

• Designed for 3-phase grounding applications
• Temperature rating of -40 to 60 degrees Celsius
• Compliant with various safety standards including UL and CSA

Product Highlights

This model features a screw terminal connection and incorporates a locking mechanism for safe disconnection from power sources.

Product Information

Standard Information

• Brand: Hubbell Wiring Device-Kellems
• MPN: L1620P

Technical Specifications

• Voltage Rating: 480 VAC
• Amperage Rating: 20 A
• Number of Poles: 3
• Number of Wires: 4
• Temperature Rating: -40 to 60 degrees Celsius
• NEMA Rating: L16-20P
• Material: Composite
• Terminal Type: Screw
